Ethernet / Serial - Converter
( Ethernet Switch inside for enter/exit connection, Serial Port: RS422 )
Prices and Shipping info
|
|
| Specifications: | |
| Ports: | 2xEthernet; 1xRS422; |
| Data Rates RS422 | Up to 115200 bps |
| RS422 connector | 5way 5mm terminal block |
| Ethernet Connector | RJ45 |
| Power Supply Connector | 2way 5mm terminal block |
| Power Supply | 8..24V AC; 12..35V DC |
| Operating temperature | -40°C/+85°C (-40°F/+185°F)/TD> |
| Dimensions | 120x23x107 (LxWxH) |
| Weight | 200g approx |
| Mechanical fixing | DIN Rail montage |
| SOFTWARE: | SW67648 |
| ORDER CODE: | HD67648-422-A1 |
