CAN / Multi-Mode Optic Fiber - Converter
( Daisy chain fiber connections allowed: Multi-drop, redundant Double loop, Point to Point )
Prices and Shipping info
|
|
| Specifications: | |
| Ports: | 1xCAN; 4xOptic Fibers |
| Data Rates CAN | Up to 1Mbps |
| CAN connector | 3way 5mm fixed screw terminal |
| Optic Fiber connector | SFP |
| Power supply | 9..19V AC; 12..35V DC |
| Operating temperature | -40°C/+85°C (-40°F/+185°F) |
| Dimensions | 71x60x95 (DxWxH) |
| Weight | 200g approx |
| Mechanical fixing | DIN Rail montage |
| Software | SW67701 |
| ORDER CODE: | HD67702-C-0-D5M-D5M |
