HD67F28-2-B2-915MHz
LoRaWAN Gateway / NMEA0183 - Converter
( LoRaWAN Gateway @ 915 MHz, Housing type: B, Terminal Blocks Connectors - NMEA0183 on RS232 )
Prices and Shipping info
Specifications:
Ports: 1xAntenna; 1xRS232; 1xEthernet;
RS232 protocolNMEA0183 on RS232
Antenna protocolLoRaWAN Gateway 915MHz
Data rates NMEA0183Up to 115200 bps
Data rates LoRaWANprogrammable
NMEA0183Connector3way 5mm terminal block
LoRaWAN Gateway ConnectorSMA Female Antenna
Power Supply Connector2way 5mm terminal block
Power Supply 15..21V AC ; 18..35V DC
Operating temperature-40°C/+85°C (-40°F/+185°F)
Dimensions71x60x95 (LxWxH)
Weight200g approx
Mechanical fixingDIN Rail montage
SOFTWARE:SW67F28
ORDER CODE:HD67F28-2-B2-915MHz
