EtherNet/IP / NMEA 2000 - Converter
( Ethernet Switch Inside for enter/exit connection,
Housing type: A, Terminal Blocks Connectors )
Prices and Shipping info
|
|
| Specifications: | |
| Ports: | 1xNMEA2000; 1xEtherNet/IP |
| Data Rates NMEA2000 | Up to 1Mbps |
| Data Rates Ethernet | 10/100 Base-T Autosensing |
| NMEA2000 connector | 3way 5mm removable screw terminal |
| Ethernet connector | RJ45 |
| Power supply | 8..24V AC; 12..35V DC |
| Operating temperature | -40° to +85° (-40°F to +185°F) |
| Dimensions | 120x23x107 (DxWxH) |
| Weight | 200g approx |
| Mechanical fixing | DIN Rail montage |
| Software | SW67589 |
| ORDER CODE: | HD67589-A1 |
