PROFINET Master / Ethernet - Converter
( Housing type: A, Terminal Blocks Connectors )
Prices and Shipping info
|
|
| Specifications: | |
| Ports: | 2xEthernet; |
| PROFINET Protocol | PROFINET Master |
| Ethernet Protocol | TCP or UDP |
| Data Rates PROFINET | 10/100 Base-T Autosensing |
| Data Rates Ethernet | 10/100 Base-T Autosensing |
| PROFINET connector | RJ45 |
| Ethernet connector | RJ45 |
| Power supply | 8..24V AC; 12..35V DC |
| Operating temperature | -40°C/+85°C (-40°F/+185°F) |
| Dimensions | 120x23x107 (DxWxH) |
| Weight | 200g approx |
| Mechanical fixing | DIN Rail montage |
| Software | SW67B84 |
| ORDER CODE: | HD67B84-A1 |
