IEC61850 / HTTP/REST - Converter


This serie of products allows to interface a http Client or Server with a IEC61850 system (Client or Server).

The converters offer a standard RESTful HTTP request/response interface and a Websocket channel for fast data exchange (for example for alarms, notifications, progresses).
It is possible to use HTTP communication with or without TLS protocol for security.

HTTP Client converters allow for a configuration to adapt to the Servers APIs.
HTTP Server converters provide a static API for exchanging data.



Order Code Price info Details Description User manual Operating Temperature
IEC 61850 Client / HTTP/REST Client series
HD67G62-B2 View IEC 61850 Client / HTTP/REST Client - Converter
(Housing type: B, Terminal Blocks Connectors) 		-40°C to +85°C
HD67G62-G43-B2 View IEC 61850 Client / HTTP/REST Client - Converter
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE ) 		-40°C to +85°C
HD67G62-G43-E-B2 View IEC 61850 Client / HTTP/REST Client - Converter
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE + eSIM ) 		-40°C to +85°C
HD67G62-G43-VPN-B2 View IEC 61850 Client / HTTP/REST Client - Converter with VPN
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE ) 		-40°C to +85°C
HD67G62-G43-E-VPN-B2 View IEC 61850 Client / HTTP/REST Client - Converter with VPN
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE + eSIM ) 		-40°C to +85°C
IEC 61850 Client / HTTP/REST Server series
HD67G63-B2 View IEC 61850 Client / HTTP/REST Server - Converter
(Housing type: B, Terminal Blocks Connectors) 		-40°C to +85°C
HD67G63-G43-B2 View IEC 61850 Client / HTTP/REST Server - Converter
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE ) 		-40°C to +85°C
HD67G63-G43-E-B2 View IEC 61850 Client / HTTP/REST Server - Converter
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE + eSIM ) 		-40°C to +85°C
HD67G63-G43-VPN-B2 View IEC 61850 Client / HTTP/REST Server - Converter with VPN
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE ) 		-40°C to +85°C
HD67G63-G43-E-VPN-B2 View IEC 61850 Client / HTTP/REST Server - Converter with VPN
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE + eSIM ) 		-40°C to +85°C
IEC 61850 Server / HTTP/REST Server series
HD67G64-B2 View IEC 61850 Server / HTTP/REST Client - Converter
(Housing type: B, Terminal Blocks Connectors) 		-40°C to +85°C
HD67G64-G43-B2 View IEC 61850 Server / HTTP/REST Client - Converter
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE ) 		-40°C to +85°C
HD67G64-G43-E-B2 View IEC 61850 Server / HTTP/REST Client - Converter
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE + eSIM ) 		-40°C to +85°C
HD67G64-G43-VPN-B2 View IEC 61850 Server / HTTP/REST Client - Converter with VPN
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE ) 		-40°C to +85°C
HD67G64-G43-E-VPN-B2 View IEC 61850 Server / HTTP/REST Client - Converter with VPN
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE + eSIM ) 		-40°C to +85°C
IEC 61850 Server / HTTP/REST Server series
HD67G65-B2 View IEC 61850 Server / HTTP/REST Server - Converter
(Housing type: B, Terminal Blocks Connectors) 		-40°C to +85°C
HD67G65-G43-B2 View IEC 61850 Server / HTTP/REST Server - Converter
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE ) 		-40°C to +85°C
HD67G65-G43-E-B2 View IEC 61850 Server / HTTP/REST Server - Converter
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE + eSIM ) 		-40°C to +85°C
HD67G65-G43-VPN-B2 View IEC 61850 Server / HTTP/REST Server - Converter with VPN
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE ) 		-40°C to +85°C
HD67G65-G43-E-VPN-B2 View IEC 61850 Server / HTTP/REST Server - Converter with VPN
(Housing type: B, Terminal Blocks Connectors ,Connectvity: LAN + SIM LTE + eSIM ) 		-40°C to +85°C
IEC 61850 / HttpRest - Structured Cabling
HD67G62-SCB View IEC 61850 Client / HTTP/REST Client for Structured Cabling IP67 - Converter (IIoT port MQTT, OPC UA, M12 Connectors, Color Carbon Black) -40°C to +85°C
HD67G62-SCK View IEC 61850 Client / HTTP/REST Client for Structured Cabling IP69K - Converter (IIoT port MQTT, OPC UA, M12 Connectors, Color Light Grey) -40°C to +85°C
HD67G63-SCB View IEC 61850 Client / HTTP/REST Server for Structured Cabling IP67 - Converter (IIoT port MQTT, OPC UA, M12 Connectors, Color Carbon Black) -40°C to +85°C
HD67G63-SCK View IEC 61850 Client / HTTP/REST Server for Structured Cabling IP69K - Converter (IIoT port MQTT, OPC UA, M12 Connectors, Color Light Grey) -40°C to +85°C
HD67G64-SCB View IEC 61850 Server / HTTP/REST Client for Structured Cabling IP67 - Converter (IIoT port MQTT, OPC UA, M12 Connectors, Color Carbon Black) -40°C to +85°C
HD67G64-SCK View IEC 61850 Server / HTTP/REST Client for Structured Cabling IP69K - Converter (IIoT port MQTT, OPC UA, M12 Connectors, Color Light Grey) -40°C to +85°C
HD67G65-SCB View IEC 61850 Server / HTTP/REST Server for Structured Cabling IP67 - Converter (IIoT port MQTT, OPC UA, M12 Connectors, Color Carbon Black) -40°C to +85°C
HD67G65-SCK View IEC 61850 Server / HTTP/REST Server for Structured Cabling IP69K - Converter (IIoT port MQTT, OPC UA, M12 Connectors, Color Light Grey) -40°C to +85°C






Accessories:
Order Code   Description Details
AC34011   Isolated Converter 100..240V AC to 12V DC stabilized - AC/DC View
AC34012   Isolated Converter 100..240V AC to 24V DC stabilized - AC/DC View
AC34131   Patch Cross Cable Cat6 2 Meters View
All Products










































Sample within:

Europe: One days
U.S.A.: Two days
Other Countries: Three days
