J1939 & NMEA2000 REPEATER/ISOLATOR

The ranges includes various products for solving all the needs of a CAN line like extension of the line, increase of nodes number, isolation of J1939 and NMEA2000 branches, protection from spikes noise and electrostatic charger or simply to change the communication baudrate.

The HD67182 and HD67182M devices are repeaters/isolators for J1939 and NMEA2000 buses.

The HD67182R, HD67182-A3 and HD67181-A4 devices are repeaters/isolators with a 3kV isolation between the two J1939 and NMEA2000 bus.

The HD67182F and the HD67182FSX are generic J1939 and NMEA2000 repeaters that allows to extend a J1939 and NMEA2000 network through Multi-Modal optic fiber.

The converters are available also in another version, ideal for STRONG applications.

The corresponding models are:

HD67404 – J1939 and NMEA2000 Repeater, STRONG

These converters are contained in a metal housing, so it is STRONG and RESISTANT to the vibrations and shocks. The electrical parts are with triple isolation of 4000 V between CAN/CAN - CAN/Power Supply - CAN/Power Supply.
Particularly suitable for the installation on cars, trains, boats, industrial sector and in fragile environments.
Two versions, one with Varnished PCB and one with Resined PCB.
Varnished treatment gives dust and humidity protection, Resined treatment gives high water, dust and vibrations protection.
Excellent range of temperature resistance from -40°C to +105°C, features required by AUTOMOTIVE applications.

HD67182

HD67182M

HD67182R

HD67182-A3

HD67182-A4

HD67182FSX

HD67404

Order Code	Price Info	Details	Description	User manual	Operating Temperature
Series J1939 Repeater
HD67182		View	J1939 and NMEA 2000 - Repeater - Extender bus line ( Housing type: A, Terminal Blocks Connectors )		-40°C to +85°C
HD67182M		View	J1939 and NMEA 2000 - Repeater - Extender bus line ( Housing type: Small Size, Terminal Blocks Connetors )		-40°C to +85°C
HD67182R		View	J1939 and NMEA 2000 - Repeater - Extender bus line ( Housing type: R, Terminal Blocks Connectors, Galvanic Isolation: 3KV )		-40°C to +85°C
HD67182-A3		View	J1939 and NMEA 2000 - Repeater - Extender bus line ( Housing type: A, M12 Connectors, Galvanic Isolation: 3KV )		-40°C to +85°C
HD67182-A4		View	J1939 and NMEA 2000 - Repeater - Extender bus line ( Housing type: A, Mni-Fit Connectors, Galvanic Isolation: 3KV )		-40°C to +85°C
HD67404		View	J1939 and NMEA 2000 - Repeater - Extender bus line ( Metal enclosure, Triple Galvanic Isolation: 4KV, PCB Treatment )		-40°C to +105°C
Series J1939 Repeater Optic fibres
HD67182F		View	J1939 and NMEA 2000/Optic Fibres - Repeater - Extender bus line		-40°C to +85°C
HD67182FS		View	J1939 and NMEA 2000/Optic Fibres - Repeater - Extender bus line ( High Performance )		-40°C to +85°C
HD67182FSX		View	J1939 and NMEA 2000 / Optic Fiber - Repeater - Extender bus line ( High Performance )		-40°C to +85°C
J1939 / NMEA 2000 - Structured Cabling
HD67182-SCB		View	J1939 and NMEA 2000 - Repeater - Extender bus line for Structured Cabling IP67 - Converter (IIoT port MQTT, OPC UA, M12 Connectors, Color Carbon Black)		-40°C to +85°C
HD67182-SCK		View	J1939 and NMEA 2000 - Repeater - Extender bus line for Structured Cabling IP69K - Converter (IIoT port MQTT, OPC UA, M12 Connectors, Color Light Grey)		-40°C to +85°C

Accessories:
Order Code	Description	Details
AC34011	Isolated Converter 100..240V AC to 12V DC stabilized - AC/DC	View
AC34012	Isolated Converter 100..240V AC to 24V DC stabilized - AC/DC	View
AC34107	Null Modem Cable, Fem/Fem, DSub 9 Pin, 1.8 m	View
AC34114	Null Modem Cable, Fem/Fem, DSub 9 Pin, 5 m	View
